About Indy12
Built for applications requiring greater lifting capacity, the Indy12 combines industrial performance with the simplicity of collaborative automation. It is well suited for machine tending, palletizing, assembly, material handling, and other tasks involving larger workpieces or tooling.
Like every robot in the Indy Series, the Indy12 features advanced collision detection, impedance control, and intuitive direct teaching to simplify programming and improve operator safety. Standard wrist interfaces make it easy to integrate grippers, vision systems, and application-specific tooling into virtually any production environment.
Best for
- Heavy parts
- Long reach
- Demanding cycles
Key features
- Highest payload in our lineup
- Longest reach in our lineup
- High torque
Applications
- Large structural welding
- Heavy assembly operations
- Machine tending with large parts
- Palletizing and case packing
- Material handling of heavy components
Specifications
| Payload | 12 kg |
|---|---|
| Maximum Reach | 1,700 mm |
| Repeatability | ±0.1 mm |
| Degrees of Freedom | 6 (all revolute) |
| Weight | 57 kg |
| Maximum Tool Speed | 1 m/s |
| Maximum Joint Speed | 120°/s (J1–J2) · 150°/s (J3–J6) |
| Joint Motion Range | ±360° (J1·J2·J4·J5·J6) · ±170° (J3) |
| Workspace (at full payload) | 1,200 mm |
| IP Rating | IP54 |
Indy12
Long-reach cobot
Direct Teaching
Collision Detection
Easy Programming
Simple Installation
Higher payload. Greater capability.
The Indy12 delivers the same intuitive collaborative robot experience as the Indy7 while providing a 12 kg payload for heavier parts and more demanding automation tasks.
